Reverse Circuit Board Locking Arrowhead Support
NCPS
This reverse circuit board locking arrowhead support is ideally suited to a top hole size of 4.00mm, a bottom hole size of 5.50mm, a top panel thickness of 1.60mm and a bottom panel thickness of 1.00-1.50mm. Supplied in Black Nylon 66 UL94-V2
Reverse Circuit Board Locking Support 15
- Natural Nylon 66
- UL94-HB
- RoHS Compliant
- Operating Temperature -35°C to +85°C
- Top Hole size - 4.00mm
- Top Panel Thickness - 1.60mm
- Bottom Hole size - 5.50mm
- Bottom Panel Thickness - 1.00-1.50mm
Supplied in packs of 1000
Downloads
Reverse PCB Support Arrowhead
| Product Code | Length | Price per pack | Quantity | |
|---|---|---|---|---|
| NCPS-5-66 | 5.00mm | £49.82 |
|
|
| NCPS-6-66 | 6.00mm | £49.82 |
|
|
| NCPS-8-66 | 8.00mm | £49.82 |
|
|
| NCPS-10-66 | 10.00mm | £52.90 |
|
|
| NCPS-12-66 | 12.00mm | £52.90 |
|
|
| NCPS-14-66 | 14.00mm | £52.90 |
|
|
| NCPS-16-66 | 16.00mm | £52.90 |
|
|
| NCPS-18-66 | 18.00mm | £52.90 |
|
|
| NCPS-20-66 | 20.00mm | £52.90 |
|
|
| NCPS-22-66 | 22.00mm | £57.02 |
|
|
| NCPS-24-66 | 24.00mm | £57.02 |
|
